Clinical and radiological findings: A 63 year old female following a fall from a domestic ladder who sustained this complex proximal tibia fracture with lateral plateau impression, metaphyseal comminution and diaphyseal dissociation. A closed injury with significant soft tissue swelling and superficial abrasions - the patient was initially managed in a external fixator for compartment observation and subsequent soft tissue consolidation pending definitive surgical fixation.
Planning remarks:
The initial surgical approach commenced medially where a good read of the medial column allowed anatomical reduction of the medial column with a short monocortical 3.5 millimetre plate. This provided a basis to then reconstruct the lateral column before attending to articular reduction of the lateral joint surface. As the medial side was the primary reduction axis the medial column was supported full length allowing loads to transfer distally into the diaphysis. The medial approach was kept small and distal plate fixation was done in a minimally invasive fashion. The lateral approach was a classical incision over the lateral aspect of the anterolateral tibia to the lateral femoral epicondyle with a classical ITB split and submeniscal arthrotomy the joint was reduced under direct vision with fragment specific subchondral screw fixation from the posterolateral corner before anterolateral plating. The proximal locking screws worked as a rafting construct, supporting the lateral plateau. The lateral column was reconstructed and fixed to the diaphysis. Given the degree of depression in the lateral plateau a a period of partial weight bearing was followed before full weight bearing at 8 weeks.
This transcript was generated by https://otter.ai
contact us for advertising opportunities
Article viewed 720 times
16 Jan 2023
Add to Bookmarks
Full Citation
Cite this article:
Oates, E.J. (2023). Combined tibial metaphysis and plateau fracture. Journal of Orthopaedic Surgery and Traumatology. Case Report 12471641 Published Online Jan 16 2023.
