Nail + plate + screw hybrid fixation of a comminuted tibial plateau and metaphysis


Score and Comment on this Case

Select a Score out of 10, and add a comment in the field below

Respectfully consider international variabilty in surgical technique and implants when commenting.
Protected by reCAPTCHA - Privacy and Terms


Clinical Details

Clinical and radiological findings:  37 year-old male. EtOH use disorder. T2DM with A1C 12.7 on admission. Glucose during hospital admission 2-400s. Consideration was given to an open reduction and internal fixation using a locked plate construct. However, given the patient's poor compliance and uncontrolled diabetes, a minimally invasive weight bearing hybrid fixation was preferred.

Preoperative Plan

Planning remarks:

Surgical Discussion

Operative remarks:

Provisional reduction and fixation of the minimally displaced plateau was achieved using k-wires and isolated percutaneous screws. This restored the articular surface of the lateral condyle and stabilised the articular block for subsequent nailing. A further screw stabilisation of a tibial tubercle fracture was done, stabilising the tubercle to the posterior cortex with lag screws, taking into consideration the future path of the nail. Following unremarkable introduction of the nail Secondary support of the medial cortical column was done with a percutaneously placed plate. This was secured in a minimally invasive fashion without significant soft tissue injury. Case credit: Matthew Wharton, University of New Mexico.

Orthopaedic implants used:   This transcript was generated by https://otter.ai
