Radial head reconstruction with a 1.7mm antiglide plate


Score and Comment on this Case

Select a Score out of 10, and add a comment in the field below

Respectfully consider international variabilty in surgical technique and implants when commenting.
Protected by reCAPTCHA - Privacy and Terms


Clinical Details

Clinical and radiological findings:  This is a 20-something year old female who sustained play radial head fracture likely in context of a transient elbow dislocation following a sporting incident. Referred from another centre the patient presented in an above elbow splint approximately one week post injury. She had been advised that the injury was not reconstructible and would require a radial head replacement. Indeed a large fragment of radial head is grossly displaced however there is minimal comminution and for a 20-year old certainly deserves an attempt at joined conserving reconstruction.

Preoperative Plan

Planning remarks:

Surgical Discussion

Operative remarks:

This operation was done supine with the arm freely draped and positioned on a small table to the side. A lateral approach directly to the radio head through kaplans interval was used (well, formally you would say to kaplans interval represents probably just an EDC split). This approach provided direct access to the fracture using a relatively small surgical incision of around 5-6cm. The radial head fragment was retrieved but before reduction, absorbable k wires were used to stabilise the fractured but non displaced residual head fragment on the far ulnar side. The the head fragment was then anatomically reduced and fixed with two headless bone screws in a quasi tripod technique. Given the size of the fragment and the oblique nature of the neck extension an additional 1.7 mm Leibinger anti glide plate was implanted to prevent axial migration through wedge forces. 3 months post-op the patient describes a 95% recovery of elbow and arm function and has radiological bony union and unchanged osteosynthetic hardware. I even received a postcard explaining how happy the patient is to have retained her native radial head.
